Image Sensor | 1/1.3-inch CMOS, Effective Pixels: 12 MP |
Lens | FOV: 82.1° Format Equivalent: 24 mm Aperture: f/1.7 Focus: 1 m to ∞ |
ISO Range | Video: 100-3200 Photo: 100-3200 |
Shutter Speed | Electronic Shutter: 2-1/8000 s |
Max Image Size | 4000×3000 |
Max Video Bitrate | 100 Mbps |
Supported File System | FAT32 (≤ 32 GB) exFAT (> 32 GB) |
QuickShots Modes | Dronie, Helix, Rocket, Circle, and Boomerang |
Aircraft
Takeoff Weight | < 249 g |
Dimensions | Folded (without propellers): 148×90×62 mm (L×W×H) Unfolded (with propellers): 251×362×72 mm (L×W×H) |
Max Ascent Speed | 5 m/s |
Max Descent Speed | 3.5 m/s |
Max Horizontal Speed (at sea level, no wind) | 16 m/s |
Max Takeoff Altitude | With Intelligent Flight Battery: 4000 m With Intelligent Flight Battery Plus*: 3000 m |
Max Flight Time | 38 minutes (with Intelligent Flight Battery) 51 minutes (with Intelligent Flight Battery Plus*) |
Max Hovering Time | 33 minutes (with Intelligent Flight Battery) 44 minutes (with Intelligent Flight Battery Plus*) |
Max Wind Speed Resistance | 10.7 m/s (Level 5) |
Operating Temperature | -10° to 40° C |
Internal Storage | N/A |
Gimbal
Stabilization | 3-axis mechanical gimbal (tilt, roll, and pan) |
Mechanical Range | Tilt: -135° to 80° Roll: -135° to 45° Pan: -30° to 30° |
Controllable Range | Tilt: -90° to 60° Roll: -90° or 0° |
Max Control Speed (tilt) | 100°/s |
Angular Vibration Range | ±0.01° |
Remote Kontrol
Max Operating Time | DJI RC-N1 Remote Controller Without charging any mobile device: 6 hours When charging a mobile device: 4 hours |
Max Supported Mobile Device Size | DJI RC-N1 Remote Controller 180×86×10 mm (L×W×H) |
Operating Temperature | DJI RC-N1 Remote Controller -10° to 40° C |
Transmission Power (EIRP) | DJI RC-N1 Remote Controller 2.400-2.4835 GHz: < 26 dBm (FCC) < 20 dBm (CE/SRRC/MIC)5.725-5.850 GHz: < 26 dBm (FCC) < 23 dBm (SRRC) < 14 dBm (CE) |
Baterai
Capacity | Intelligent Flight Battery: 2453 mAh Intelligent Flight Battery Plus*: 3850 mAh |
Type | Li-ion 4S |
Energy | Intelligent Flight Battery: 18.1 Wh Intelligent Flight Battery Plus*: 28.4 Wh |
Weight | Intelligent Flight Battery: Approx. 80.5 g Intelligent Flight Battery Plus*: Approx. 121 g |
Charging Temperature | 5° to 40° C |
Charging Time | Intelligent Flight Battery: 64 minutes (with the DJI 30W USB-C Charger and the battery mounted to the aircraft) 56 minutes (with the DJI 30W USB-C Charger and the battery inserted into the Two-Way Charging Hub)Intelligent Flight Battery Plus*: 101 minutes (with the DJI 30W USB-C Charger and the battery mounted to the aircraft) 78 minutes (with the DJI 30W USB-C Charger and the battery inserted into the Two-Way Charging Hub) |
Recommended Charger | DJI 30W USB-C Charger or other USB Power Delivery chargers (30 W)* * Saat Anda mengisi baterai yang terpasang di aircraft atau dimasukkan ke Two-Way Charging Hub, daya pengisian maksimum yang didukung adalah 30 W. |
Sensing System
Sensing Type | Downward vision system |
Downward | Precise Hovering Range: 0.5-10 m |
Operating Environment | Downward: Diffuse reflective surfaces with a clear pattern and reflectivity > 20% (such as walls, trees, or people) Adequate lighting (lux > 15, normal indoor lighting conditions) |
Lainnya
Video Transmission System | DJI O2 |
Live View Quality | Remote Controller: 720p/30fps |
Max Transmission Distance (free of interference) | FCC: 10 km CE: 6 km SRRC: 6 km MIC: 6 km |
